• Low Quiescent Current: 100μA at 5V
• High PSRR: 65dB range to 1KHz
• Low Output Noise: 44uVRMS
• Low Dropout: 200mV@Iout=0.8A, Vout=3.3V
• Maximum output current: 1A
• Highly Accurate: ±2%
• Low ESR Ceramic Capacitor Compatible

BL8073 series are a group of positive voltage output, high precise, and low power consumption voltage regulator. Voltages are selectable in 100mV steps within a range of 1.2V to 5.0V. It also can be customized on command. BL8073 series have excellent load and line transient response and good temperature characteristics, which can assure the stability of chip and power system. And it uses trimming technique to guarantee output voltage accuracy within ±2%. BL8073 series are available in SOT-23-5 and SOT- 89-3 packages, which are lead (Pb)- free.
