• SA2530-V1.0.pdf

  （Documentation）

  ALL

• Fully operational to 25V
• 3.3/5/25V input logic compatible
• 1.0A/1.5A(typ.) current capability
• Tolerant to negative transient voltage
• Fast propagation delays
• SOT23-5 package available

The SA2530 is single channel high speed, low-side, gate driver device capable of effectively driving MOSFET and IGBT power switches. The SA2530 is designed to operate over a wide VDD range of 5.0 V to 25 V and wide temperature range of –40°C to 125°C. Internal Undervoltage Lockout (UVLO) circuitry on VDD pin holds output low outside VDD operating range. The capability to operate at low voltage levels such as below 5 V, along with best-in-class switching characteristics, is especially suited for driving emerging wide band-gap power-switching devices such as GaN power semiconductor devices.
