EnglishCurrent-Mode PWM Driver Controller、SOT23-6/SOP8、Wide VDD (9.5-52V)、70KHz、Low Standby Power、Adaptive Soft Drive、Charger/Set-Top Box 进入 AI 阅读 请再提供一些关于ME8226B的详细信息。 产品类型为电流模式PWM驱动控制器的应用领域有哪些？ 宽VDD的具体含义是什么？
- 低启动电流，待机功耗<75mW
- 超宽 VDD 供电范围 9.5V~52V
- 软启动功能
- 频率抖动和峰值电流抖动
- 轻载打嗝模式及噪音优化
- 自适应软驱动功能
- 前沿消隐
- 内置斜坡补偿
- 集成自恢复模式保护：OCP, OLP, UVLO, VDD OVP, OTP, LEB, SCB
The ME8226B is a highly integrated current mode PWM controller optimized for high performance off-line power converters. VDD low startup current and low operating current contribute to a tiny power consumption and reliable power on startup. ME8226B features a auto-tuning circuit combined with a steering charge pump，ensuring stable driving speed for various Qg conditions without any external resistor. ME8226B offers a wide VDD supply range from 9.6V to 52V. The IC operates in a maximum frequency of 70KHz @Full Load, As the load gradually decreases ，the IC operates in Green Mode and Extended Burst Mode to minimize the standby power loss. EMI performance is also optimized by Frequency Jittering and Peak Current Jittering. ME8226B offers comprehensive protection coverage including Cycle-by-Cycle current limiting（OCP），Over Load Protection（OLP），VDD Under Voltage Lockout （ UVLO ）， Over Temperature Protection（OTP），VDD Over Voltage Protection（VDD OVP），Leading Edge Blanking（LEB）and CS open Protection（SCB）.
Sample Apply
