The BL8032G is a fully integrated, high-efficiency 2A synchronous rectified step-down converter. The BL8032G operates at high efficiency over a wide output current load range. This device offers two operation modes, PWM control and PFM Mode switching control, which allows a high efficiency over the wider range of the load. The BL8032G requires a minimum number of readily available standard external components and is available in a 6-pin SOT23 ROHS compliant package.

• High efficiency: up to 96%
• 500KHz frequency operation
• 2A output current
• No schottky diode required
• 4.5V to 18V input voltage range
• 0.8V reference
• Slope compensated current mode control for excellent line and load transient response
• Integrated internal compensation
• Stable with low ESR ceramic output capacitors
• Over current protection with hiccup-mode
• Thermal shutdown
• Inrush current limit and soft start
• Available in SOT23-6
• -40℃ to +85℃ temperature range

• BL8032G Datasheet V1.4.pdf
