BL389X series operates from a single 1.8V to 5.5V supply or dual ±0.9V to ±2.75V supplies，the amplifiers offer bandwidth of 1.8MHz, rail-to-rail inputs and outputs.The BL389X amplifier is micro-power, zero-drift CMOS operational amplifiers, BL389X uses chopper stabilized technique to provide very low offset voltage (less than 30µV maximum) and near zero drift over temperature. The BL389X offers excellent CMRR without the crossover associated with traditional complementary input stages.
The BL3891 is available in SOT23-5 and SOP-8 packages. And the BL3892 is available in MSOP-8 and SOP-8 packages. The BL3894 Quad is available in Green SOP-14 and TSSOP-14 packages.

• • 1.4V 至 5.5V 的工作范围内提供轨到轨输入
• • Vos: 30uV
• • Zero Drift: 0.01μV/°C
• • 增益带宽积 1.8MHZ
• • 低偏置电流: 20pA (Typ)
• • 工作温度范围从 -40 °C到 125 °C
• • 提供多种封装

• BL3891_3892_3894 V1.1.pdf
